Maximize your margins with Aumotive Display - industry-leading quality meeting soaring market demand.
Super narrow border
The lower frame of the module adopts a die-casting design, integrating it with the Tier1 customer's rear housing to reduce the bezel and overall thickness of the TPM assembly.
Extremely-integrated black panel
Adjust the display panel and cover glass, along with the series parameters of the 3A film material, to achieve an indistinguishable display area and BM (Black Matrix) region to the naked human eye.
Ultra-low reflectivity
Utilizing multi-layer precision coating technology and optical structural design.
Ultra-high contrast
Ultra-narrow bezel process, reducing the width of the black border to enhance the display area.
| Item/Size & Model Name | 7 | 7 | 7 | 8 | 8.8 | 9 | 9 | 9.2 | 10.1 |
| Application scenarios | Cluster | Cluster | Cluster | CID | Cluster/CID | Cluster/CID | CID | Cluster/CMS | Cluster/CID/PID |
| Resolution | 800*480 | 1024*600 | 1024*600 | 800*480 | 1280*480 | 1024*600 | 1280*720 | 1920*384 | 1024*600 |
| Luminance (nits) (LCM) | min 800 typ 1000 | min 550 typ 600 | min 500 typ 550 | min 650 typ 800 | min 700 typ 850 | min 500 typ 600 | min 800 typ 1000 | NA | min 500 typ 600 |
| Remark (NTSC) | NSTC 67% | NSTC 75% | NSTC 75% | NSTC 75% | NSTC 70% | NSTC 50% | NSTC 70% | NSTC 53% | NSTC 70% |
| Item/Size & Model Name | 10.25 | 10.25 | 10.25 | 12.3 | 12.3 | 12.3 | 15.6 |
| Application scenarios | Cluster/CID/PID | Cluster/CID/PID | /CID/PID | Cluster/CID/PID | Cluster/CID/PID | Cluster/CID/PID | CID/PID |
| Product Type | TPM | TPM | LCM | TPM Dual Display | LCM | TPM | TPM |
| Resolution | 1920*720 | 1920*720 | 1280*480 | 1920*720 | 1920*720 | 1920*720 | 1920*1080 |
| Luminance (nits) (LCM) | min 835 typ 1000 | min 835 typ 1000 | min 800 typ 1000 | min 800 | min 80 typ 1000 | min 530 typ 610 | min 800 typ 900 |
| Remark (NTSC) | NSTC 75% | NSTC 75% | NSTC 75% | NSTC 80% | NSTC 80% | NSTC 80% | NSTC 72% |
We offer a strong cost advantage and benefit from a fully integrated industrial chain.
The product is primarily deployed in in-vehicle smart display systems—including the center console, instrument cluster, co-driver display, and rear-seat entertainment devices.
It delivers both experiential and commercial value:
Experiential benefits: Features such as privacy protection, eye-care technology, and a skin-like touch sensation enhance passenger comfort and usability.
Commercial advantages: A modular design, ultra-thin profile, ultra-narrow bezels, and optimized cost structure support efficient integration and scalability for automotive manufacturers.
We have supplied our products to leading automotive and Tier-1 companies, including Aumovia, Valeo, SAIC, Volkswagen, Geely, Great Wall, and XPeng.
Contact Info
Let's discuss how K&D's display solutions can bring your next-generation product to life.
