Eye protection
Using blue light filter, 9 - layer scattering, surface anti-glare technology to realize.
High color gamut
Utilizing technology of quantum-dot display technology and blue light LED to make product with higher gamut of 103% NTSC.
Narrow border
Simultaneously utilizing many kinds of technology and design to make the module boarder to extremely narrow.
Ultra-thin
The advanced glass thinning technology of K&D matching with ultra thin backlight design to realize the optimized level of lighter and thinner.
| Size | 4.3 | 6.95 | 7 | 7 | 8 | 8 | 8.68 |
| Products Application | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display |
| Resolution Ratio | 480*272 | 600*1024 | 600*1024 | 1024*600 | 800*1280 | 800*1280 | 800*1340 |
| Brightness-TPY | 400 | 600 | 300 | 300 | 250 | 350 | 500 |
| Contrast Ratio-TPY | 500 | 800 | 800 | 800 | 1000 | 1500 | 1500 |
| Size | 10.1 | 10.1 | 10.1 | 10.1 | 10.1 | 10.1 | 10.1 |
| Products Application | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display |
| Resolution Ratio | 800*1280 | 1280*800 | 1200*1920 | 800*1280 | 800*1280 | 1200*2000 | 800*1280 |
| Brightness-TPY | 330 | 350 | 500 | 280 | 330 | 350 | 280 |
| Contrast Ratio-TPY | 1000 | 800 | 1200 | 1000 | 1000 | 1500 | 1000 |
| Size | 10.36 | 10.4 | 10.4 | 10.95 | 10.95 | 11.6 | 16 |
| Products Application | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display | Tablet Display |
| Resolution Ratio | 1200*2000 | 1200*2000 | 1200*2000 | 1200*1920 | 1200*1920 | 1920*1080 | 2560*1600 |
| Brightness-TPY | 350 | 350 | 350 | 450 | 320 | 350 | 368 |
| Contrast Ratio-TPY | 1300 | 1500 | 1300 | 1500 | 1500 | 1000 | 1200 |
A tablet display is the primary visual interface and input component of a portable computing device. It typically consists of a high-resolution LCD or OLED panel, a backlight unit, and a touch sensor. At K&D, our high quality tablet displays are engineered for high clarity, slim profiles, and low power consumption, making them ideal for everything from consumer electronics to rugged industrial tablets.
We primarily offer products in the following tablet display sizes: 7 inch tablet display, 8 inch display tablet, 8.68-inch, 10.36-inch, and 10.95-inch.
Our products are available with tablet display resolution including 1280*800, 1200*1920, 800*1280, 1200*2000, 800*1280, 1920*1080 and etc. If you are interested in our high resolution tablet products, feel free to contact us at any time.
TFT-LCD: The most common and cost-effective type, known for its durability and versatility.
IPS: A premium version of LCD that offers much wider viewing angles and more accurate colors.
OLED/AMOLED: Known for deep blacks and high contrast, as each pixel emits its own light.
E-Ink: Used primarily in e-readers for low power consumption and paper-like reading.
K&D specializes in high-quality TFT-LCD and IPS smart display tablet, offering various interface options like MIPI, LVDS, and eDP to ensure compatibility with different processor platforms.
The main difference lies in the visual feedback.
A drawing tablet is a pressure-sensitive pad used with a stylus; it has no screen, so the user must look at a separate computer monitor. A display tablet allows you to draw directly onto the built-in screen. K&D provides the high-performance LCD modules and full-lamination technology required for screen display tablet, ensuring high color accuracy and minimal parallax.
